Viking Tech are leaders in the design, manufacture and marketing of Thin-Film & Thick-Film integrated passive devices and discrete passive components.
This handy selection guide offers information about the different series offered by Viking.
DMTL are the sole agent and distributor of Viking Technology in the UK.
DMTL are also direct partners and franchised distributors for the likes of ATC, E&C Finechem, HTR, Nikkohm, Riedon and State of the Art.
With a recent explosion in the need to accurately measure voltage in circuits, the Current Sense Resistor , also referred to as a Shunt Resistor, has steadily been increasing in technology options. For example; Thick Film, Thin Film, Electron Beam Welded (EBM), Metal Strip, Metal Foil & Wirewound variants.
At DMTL we offer Current Sense Resistors / Shunt Resistors, from various manufacturers; including First Ohm, HTR, Nikkohm, Riedon, State of the Art & Viking. With each manufacturer specialising in one or more of the resistive technologies outlined above.
Below, is a table of the different series offered by Viking Technology in their Current Sensing range. To download the full selection guide with images click here.
Series | P/N | Size | Power | Tolerance | Resistance | TCR/PPM |
Thin Film Precision | TCS02 | 0402 | 1/16W | ±0.5% ~ ±1% |
500MΩ ~ 1Ω | ±50, ±100, ±200 |
TCS03 | 0603 | 1/10W | ±0.5% ~ ±1% | 500MΩ ~ 1Ω | ±50, ±100, ±200 | |
TCS05 | 0805 | 1/8W | ±0.5% ~ ±1% | 200MΩ ~ 1Ω | ±50, ±100, ±200 | |
TCS06 | 1206 | 1/4W | ±0.5% ~ ±1% | 200MΩ ~ 1Ω | ±50, ±100, ±200 | |
TCS10 | 2010 | 3/4W | ±0.5% ~ ±1% | 50MΩ ~ 1Ω | ±50, ±100, ±200 | |
TCS12 | 2512 | 1W, 3W | ±0.5% ~ ±1% | 50MΩ ~ 1Ω | ±50, ±100, ±200 | |
Thick Film Low TC | CS01 | 0201 | 1/20W | ±1%, ±2%, ±5% | 100MΩ ~ 1Ω | ±300 ~ ±1000 |
CS02 | 0402 | 1/16W, 1/8W | ±1%, ±2%, ±5% | 50MΩ ~ 1Ω | ±200 ~ ±400 | |
CS03 | 0603 | 1/10W ~ 1/5W | ±1%, ±2%, ±5% | 20MΩ ~ 1Ω | ±200 ~ ±600 | |
CS05 | 0805 | 1/8W, 1/4W | ±1%, ±2%, ±5% | 10MΩ ~ 1Ω | ±200 ~ ±600 | |
CS06 | 1206 | 1/4W, 1/2W | ±1%, ±2%, ±5% | 10MΩ ~ 1Ω | ±100 ~ ±600 | |
CS13 | 1210 | 1/2W, 3/4W | ±1%, ±2%, ±5% | 10MΩ ~ 1Ω | ±100 ~ ±600 | |
CS10 | 2010 | 3/4W, 1W | ±1%, ±2%, ±5% | 10MΩ ~ 1Ω | ±100 ~ ±600 | |
CS12 | 2512 | 1W ~ 2W | ±1%, ±2%, ±5% | 10MΩ ~ 1Ω | ±100 ~ ±600 | |
NEW | CS62 | 0612 | 1W | ±1%, ±2%, ±5% | 10MΩ ~ 1Ω | ±100 ~ ±600 |
CS25 | 1225 | 3W | ±1%, ±2%, ±5% | 3MΩ ~ 8Ω | ±100 ~ ±300 | |
CS37 | 3720 | 1W | ±1%, ±2%, ±5% | 10MΩ ~ 500MΩ | ±100 ~ ±300 | |
CS75 | 7520 | 2W | ±1%, ±2%, ±5% | 1MΩ ~ 350MΩ | ±100 ~ ±300 | |
Thick Film Low Cost | RS-02 | 0402 | 1/16W, 1/10W | ±1%, ±5% | 50MΩ ~ 1Ω | ±500 ~ ±800 |
RS-03 | 0603 | 1/10W ~ 1/8W | ±1%, ±5% | 20MΩ ~ 1Ω | ±500 ~ ±1200 | |
RS-05 | 0805 | 1/8W, 1/4W | ±1%, ±5% | 10MΩ ~ 1Ω | ±500 ~ ±1500 | |
RS-06 | 1206 | 1/4W, 1/3W | ±1%, ±5% | 10MΩ ~ 1Ω | ±500 ~ ±1500 | |
RS-10 | 1210 | 1/3W, 1/2W | ±1%, ±5% | 10MΩ ~ 1Ω | ±500 ~ ±1500 | |
RS-0A | 2010 | 3/4W, 1W | ±1%, ±5% | 10MΩ ~ 1Ω | ±500 ~ ±1500 | |
RS-12 | 2512 | 1W, 2W | ±1%, ±5% | 10MΩ ~ 1Ω | ±500 ~ ±1500 |
